XTAR - SC2 - Charger for battery cells with USB-C connection
Delivery Time 1-3 working days
The XTAR SC2 is a compact, powerful USB charger, perfect for larger battery cells like 18650, 20700, and 21700, commonly used in e-cigarettes. Equipped with the TC-CC-CV charging process, it provides safe and gentle charging by starting with a reduced current, followed by constant current, and finishing with constant voltage. This ensures efficient and long-lasting battery life.
Powerful Charging Capacity for Single and Dual Use
The SC2 supports a current of up to 3A when charging one battery, or 2A when charging two batteries simultaneously, with a maximum voltage of 4.2V. It’s ideal for a wide range of battery cells.
USB-C Port for Versatile Power Sources
The USB-C port allows the charger to connect flexibly to various power sources like wall adapters, laptops, or power banks, making it especially convenient for on-the-go or home use.
Comprehensive Protection Features for Maximum Safety
The safe operation of the XTAR SC2 charger is ensured by built-in protection features like polarity reversal, short circuit, and overvoltage protection, reliably safeguarding both the device and the batteries.
Compatibility with Various Battery Sizes
The SC2 is compatible with a wide range of battery sizes, including 18350, 18650, 18700, 20700, 21700, 22650, 25500, and 26650 cells.
XTAR SC2 Charger Package Contents
- 1x XTAR SC2 charger
- 1x USB-C cable
- 1x User manual
XTAR
XTAR is a manufacturer from China that has been building chargers, batteries and torches since 2006. For battery mods, XTAR offers the SC2 charger for lithium-ion battery cells with a USB-C port.
Charging cells externally with the SC2
Many mods run on removable battery cells instead of a built-in battery. You charge the cells outside the device in the SC2: that way you always have a full cell to swap in, and the mod does not have to sit on a cable.
The SC2 charges lithium-ion cells up to the end-of-charge voltage of 4.2 V and then switches off. It draws power via USB-C, from a wall adapter, laptop or power bank.
XTAR SC2
Charger for lithium-ion battery cells, powered through a USB-C input.
- 4.2 V
end-of-charge voltage of the lithium-ion cells - USB-C
power input of the charger - China
origin
Why do I need an external charger?
For mods with removable cells. You charge one cell while the other sits in the device.
Which cells does the SC2 charge?
Lithium-ion battery cells with a 4.2 V end-of-charge voltage, as used in mods.
How is the SC2 powered?
Through the USB-C input, for example with a USB wall adapter.
Manufacturer
Shenzhen XTAR Electronics Co., Ltd.
5th Floor, No. 77 Xinhe Road, Shangmugu, Pinghu Area
Longgang District, Shenzhen, Guangdong
China
E-Mail: info@xtar.cc
Responsible Person / Importer
Shenzhen XTAR Electronics Co., Ltd.
5th Floor, No. 77 Xinhe Road, Shangmugu, Pinghu Area
Longgang District, Shenzhen, Guangdong
China
E-Mail: info@xtar.cc
| Part: | Charger |
|---|---|
| Voltage: | 4,2 V |
